CP Plus CP-EUT-6TGL23-100 – Cat6 24AWG UTP LAN Cable

SKU: CPPLUS-1837 · Model: CP-EUT-6TGL23-100

Price on request

Cat6 24AWG UTP LAN Cable

In Stock

Enquire now

Enquire on WhatsApp

Check delivery & nearest store

Enter your PIN code to find delivery options and a nearby store.

Overview

Cat6 24AWG UTP LAN Cable Features Solid Bare Electrolytic Grade Copper Insulation Polyethylene (HDPE) 4 Pair Separator Design 24 AWG cable 100 Mtr. Cable Length Specifications Conductor: Solid Bare Electrolytic Grade Copper Insulation: Polyethylene (HDPE) Nominal Conductor Diameter: 24 AWG Pairing: 2 insulated conductors twisted together Separator: Each pair separated with a cross separator Separator Material: Polyethylene (PVC) Outer Sheath: FR PVC Colour of Sheath: Grey Approximate OD: .5mm ± 0.1mm Sheath Thickness: .48mm ± .05mm Rip Cord: Yes Sequential Marking: Every Meter Characteristic Impedance: 100 ±15Ω Resistance Unbalance: 5% Max Nominal Velocity of Propagation: 69% Conductor Resistance: ≤9.38/100m Capacitance Unbalance: 330pF/100m Bending Radius: < 4 x Cable Diameter at -20° ±1°C Delay Skew: <45nS Mutual Capacitance: <5nf/100m Packing: 100 Mtrs Temperature Rating: -15 to 60°C Storage Temperature: 0 to 50°C Impedance: 100±15% Ω Pulling Force: 11.5Kg

Full specifications

Packing	100 Mtrs
Pairing	2 insulated conductors twisted together
Rip Cord	Yes
Conductor	Solid Bare Electrolytic Grade Copper
Impedance	100±15% Ω
Separator	Each pair separated with a cross separator
Delay Skew	<45nS
Insulation	Polyethylene (HDPE)
Outer Sheath	FR PVC
Pulling Force	11.5Kg
Approximate OD	.5mm ± 0.1mm
Bending Radius	< 4 x Cable Diameter at -20° ±1°C
Colour of Sheath	Grey
Sheath Thickness	.48mm ± .05mm
Mutual Capacitance	<5nf/100m
Separator Material	Polyethylene (PVC)
Sequential Marking	Every Meter
Temperature Rating	-15 to 60°C
Storage Temperature	0 to 50°C
Conductor Resistance	≤9.38/100m
Resistance Unbalance	5% Max
Capacitance Unbalance	330pF/100m
Characteristic Impedance	100 ±15Ω
Nominal Conductor Diameter	24 AWG
Nominal Velocity of Propagation	69%

What’s in the box

Confirm the supplied items with our team.

Warranty

Warranty information will be confirmed before purchase.
