CP Plus CP-EUT-6TSRD-100 – Cat6, 4 Pair UTP Cable
CP Plus

CP Plus CP-EUT-6TSRD-100 – Cat6, 4 Pair UTP Cable

SKU: CPPLUS-2139 · Model: CP-EUT-6TSRD-100

Price on request
  • Cat6, 4 Pair UTP Cable

In Stock

Enquire now
Enquire on WhatsApp

Enter your PIN code to find delivery options and a nearby store.

Overview

Cat6, 4 Pair UTP Cable Features Insulation Material HDPE Insualtion Thickness 0.20mm 100 Mtr. Cable Length Specifications Material: CCA Nominal Conductor Diameter: 0.50mm Insulation Material: HDPE No. of Strands: 1 nos (nom) Cabling Material: Polyethylene Jacket Material: PVC Color: Blue - White/ Blue Green - White/ Green Brown - White/ Brown Colour of Sheath: Natural Dielectric Strength: 12.50 N/sq.mm (min) Rip Cord: Nylone Colour of Jacket: Black Insulation Dia (Nominal): 0.90mm +/- .03 Material PVC: Polyethylene Elongation: 300% (min) Outer Dia.: 6.60mm ± 0.03 mm Insulation Thickness: 0.20 mm (nom) ± .03 Elongation in PVC Jacket: 150% (min) Length: 100 Mtr. Cable Weight: 11.200 Kg +/- 0.2kg Tensile: 17.50 N/sq. mm (min) Thickness of Outer Jacket: 0.60 ± 0.05 mm

Full specifications
ColorBlue - White/ Blue Green - White/ Green Brown - White/ Brown
Length100 Mtr.
Tensile17.50 N/sq. mm (min)
MaterialCCA
Rip CordNylone
Elongation300% (min)
Outer Dia.6.60mm ± 0.03 mm
Cable Weight11.200 Kg +/- 0.2kg
Material PVCPolyethylene
No. of Strands1 nos (nom)
Jacket MaterialPVC
Cabling MaterialPolyethylene
Colour of JacketBlack
Colour of SheathNatural
Dielectric Strength12.50 N/sq.mm (min)
Insulation MaterialHDPE
Insulation Thickness0.20 mm (nom) ± .03
Elongation in PVC Jacket150% (min)
Insulation Dia (Nominal)0.90mm +/- .03
Thickness of Outer Jacket0.60 ± 0.05 mm
Nominal Conductor Diameter0.50mm
What’s in the box

Confirm the supplied items with our team.

Warranty

Warranty information will be confirmed before purchase.
