CP Plus CP-EUT-6TSRH-305 – Cat6, 4 Pair UTP Cable
CP Plus

CP Plus CP-EUT-6TSRH-305 – Cat6, 4 Pair UTP Cable

SKU: CPPLUS-2220 · Model: CP-EUT-6TSRH-305

Price on request
  • Cat6, 4 Pair UTP Cable

In Stock

Enquire now
Enquire on WhatsApp

Enter your PIN code to find delivery options and a nearby store.

Overview

Cat6, 4 Pair UTP Cable Features Insulation Material HDPE Insualtion Thickness 0.20mm 305 Mtr. Cable Length Specifications Material: CCA Nominal Conductor Diameter: 0.50mm Insulation Material: HDPE No. of Strands: 1 nos (nom) Insulation Thickness: 0.60 ± 0.05 mm Jacket Material: PVC Color: Green - White/ Green Brown - White/ Brown & Orange - White/ Orange Dielectric Strength: 12.50 N/sq.mm (min) Rip Cord: Nylone Material PVC: Polyethylene Elongation: 300% (min) Elongation at break: 150% (min) Outer Dia.: 5.70mm ± 0.03mm Length: 305 Mtr. Tensile: 17.50 N/sq. mm (min) Thickness of Outer Jacket: 0.60 ± 0.05 mm

Full specifications
ColorGreen - White/ Green Brown - White/ Brown & Orange - White/ Orange
Length305 Mtr.
Tensile17.50 N/sq. mm (min)
MaterialCCA
Rip CordNylone
Elongation300% (min)
Outer Dia.5.70mm ± 0.03mm
Material PVCPolyethylene
No. of Strands1 nos (nom)
Jacket MaterialPVC
Dielectric Strength12.50 N/sq.mm (min)
Elongation at break150% (min)
Insulation MaterialHDPE
Insulation Thickness0.60 ± 0.05 mm
Thickness of Outer Jacket0.60 ± 0.05 mm
Nominal Conductor Diameter0.50mm
