CP Plus CP-UNC-VC41L5C-VMD-LQ – 4MP Dual Light Vandal Dome Camera - 50Mtr.

4MP Dual Light Vandal Dome Camera - 50Mtr. Features 1/2.7" 4MP PS CMOS Image Sensor (0.9407 Centimeters) Max. 4MP (2688 × 1520)/ (2560 × 1440)@1–25/30fps Instastream, H.265, H.264, H.264H, H.264B, MJPEG Support Quad Stream WDR(120dB), Day/Night(ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking Support Built-in Mic IR Range of 50 Mtr., Warm Light Range of 30 Mtr. 3.6mm Lens (2.8mm Optional) Support Starlight Technology Micro SD Card, PoE, IP67, IK10 Specifications Image Sensor: 1/2.7" 4MP PS CMOS Image Sensor (0.9407 Centimeters) Effective Pixels: 2688 (H) × 1520 (V) Minimum Illumination: 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on) Electronic Shutter: Auto/Manual 1/3 s–1/100,000 s RAM: 128 MB ROM: 128 MB White Balance: Auto, Natural, Street lamp, Outdoor, Manual, Regional custom Gain Control(AGC): Auto/ Manual Lens Type: Fixed-focal Max. Aperture: F1.4 Lens Mount: M12 Close Focus Distance: 3.6mm: 1.7 m; 2.8mm: 1.1 m Lens: 3.6mm (2.8mm Optional) Day/Night: Auto(ICR)/Color/B/W S/N Ratio: >58 dB Back Light Compensation: BLC/ HLC/ WDR(120dB) Angle Adjustment: Pan: 0°–355°, Tilt: 0°–65°, Rotation: 0°–355° Angle of view: 3.6mm: H: 83°; V: 43°; D: 100° ; 2.8mm: H: 102°; V: 54°; D: 121° DORI Distance: 3.6mm: 85.4 m (Detect), 34.2 m (Observe), 17.1 m (Recognize), 8.5 m (Identify) ; 2.8mm: 63.6 m (Detect), 25.4 m (Observe), 12.7 m (Recognize), 6.4 m (Identify) Resolution: 4MP (2688 × 1520/ 2560 × 1440), 3MP (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 x 960) ; 720p (1280 × 720), D1 (704 × 576/ 704 × 480), VGA (640 × 480), CIF (352 × 288/ 352 × 240) IR Number: 3 IR LED, 4 Warm light Warm Light: Warm Light Range of 30 Mtr. IR: IR Range of 50 Mtr. Smart Illumination: Support IR Control: Auto, Manual Stream Capability: Quad Stream Frame Rate: Main stream: 4MP (2688 x 1520/ 2560 x 1440)@1–25/30fps, 3MP (2304 x 1296)@1–25/30fps, ; 2MP (1920 × 1080)@1–25/30fps, 1.3MP (1280 × 960)@1–25/30fps, 720p (1280 × 720)@1 ; 25/30fps ; Sub stream 1: 720p (1280 × 720)@1–25/30fps, D1 (704 × 576 / 704 × 480)@1–25/30fps, VGA ; (640 × 480)@1–25/30fps, CIF (352 × 288/ 352 × 240)@1–25/30fps ; Sub Stream 2: D1 (704 × 576/ 704 × 480)@1–25/30fps, VGA (640 × 480)@1–25/30fps, CIF (352 ; × 288/ 352 × 240)@1–25/30fps ; Sub Stream 3: D1 (704 × 576/ 704 × 480)@1fps Video Compression: Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream) Noise Reduction: 3D NR Motion Detection: OFF/ON (4 areas, rectangular) IVS (Perimeter Protection): Tripwire, Intrusion, IMD (Intelligent motion detection) Privacy Mask: 4 areas Video Format: PAL/NTSC Iris Control: Fixed, DC Iris (optional) ROI: Support (4 areas) Audio: Built-in Mic Audio Input: 1 Channel (RCA port) Audio Compression: PCM, G.711a, G.711Mu, G.726, AAC Audio Output: 1 Channel (RCA port) OSD: Camera title, Date & Time Alarm IN: 1 Channel in: wet contact, 5 mA 3–5 VDC Alarm Out: 1 Channel out: wet contact, 300 mA 12 VDC Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) SDK and API: Support IMD (Intelligent motion detection): Support Dual Power Backup: When the power adapter and PoE provide power at the same time, disconnect one of them. ; The device will continue to work, but will not restart Ethernet: RJ-45 (10/100 Base-T) Mirror Function: Support Bit Rate Control: CBR/VBR Bit Rate: H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps Alarm Event: Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Tripwire, ; Intrusion, Scene changing, Audio detection, External alarm, IMD (Intelligent motion detection), ; Security exception Cyber Security: AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, ; WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, ; trusted boot Browser: IE: IE11, Chrome, Firefox Protocol: SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, ; PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, RTMP, SMTP, RTSPS, ONVIF (Profile S, Profile G, ; Profile T), unicast, multicast User/Host: 6 (Total bandwidth: 36 M) Storage: SFTP, Mirco SD card (Max. 512GB) Weatherproof Standard: IP67, IK10 Hardware Reset Point: Support Certificates: ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report Power Source: 12 VDC/PoE (802.3af) Power Consumption: Basic: 2.4 W (12 VDC), 3 W (PoE); ; Max.: 6.6 W (12 VDC), 7.9 W (PoE) (H.265 + intelligence on+ WDR + illuminator intensity) Operating Temperature: –40 °C to +60 °C Operating Humidity: ≤95% (RH), non-condensing Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F) Storage Humidity: ≤95% (RH), non-condensing Casing: Metal Dimension: 81.0 mm × 109.9 mm Weight: 350g

Confirm the supplied items with our team.

Warranty information will be confirmed before purchase.
