CP Plus CP-UNR-4K2162-V3 – 16Ch. 4K Network Video Recorder

16Ch. 4K Network Video Recorder Features Up to 16 Channel IP Camera input Instastream, H.265, H.264+, H.264, MJPEG AI by Recorder: Support 4 channel SMD AI by Camera: Support perimeter protection and SMD Max. 144/144/72 Mbps incoming/recording/outgoing bandwidth Support 2 SATA HDDs up to 20TB, 2 USB ports(2.0) HDMI / VGA simultaneous video output Mobile Software: iCMOB, gCMOB CMS Software: KVMS Pro Lite Specifications Processor: Industrial-grade processor Operating System: Embedded LINUX IP Camera Input: 16 channel User Interface: Web, Local GUI AI by Recorder: SMD AI by Camera: Perimeter protection, SMD Perimeter Performance of AI by Camera: All channels (4 targets/s) Video Output: 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Video Compression: H.265, H.264+, H.264, MJPEG Encode Strategy: Instastream Decoding Capability: AI disabled: 1 channel 12 MP@30 fps, 1 channel 8 MP@30 fps, 2 channel 6 MP@30 fps, 2 channel 5 MP@30 fps, 3 channel 4 MP@30 fps, 6 channel 1080p@30 fps AI enabled: 1 channel 8 MP@30 fps, 1 channel 6 MP@30 fps, 1 channel 5 MP@30 fps, 2 channel 4 MP@30 fps, 4 channel 1080p@30 fps Video Resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 2MP, 720p, 960p, D1, CIF, QCIF Video Display Split: 1/4/8/9/16 SMD Plus by NVR: 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change SMD Plus by Camera: All channels (8 targets/s) Network Bandwidth: AI disabled: 144 Mbps incoming, 144 Mbps recording and 72 Mbps outgoing AI enabled: 72 Mbps incoming, 72 Mbps recording and 36 Mbps outgoing Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, InstaOn, Auto Registration, ONVIF 23.12(Profile T, Profile S, Profile G), CGI, SDK Abnormality Alarm: Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline Intelligent Alarm: Perimeter protection; SMD+ General Alarm: Motion detection, Camera external alarm, PIR alarm Alarm Linkage: Recording, Snapshot, Buzzer, Log, Preset, Email, Tour Audio Input: 1 channel RCA Audio Output: 1 channel RCA Audio Compression: G.711a, G.711u, PCM, G726, AAC Hard Disk: 2 SATA ports. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature Multi-channel Playback: Up to 16 channels Record Mode: General, Motion detection, Intelligent, Alarm Playback Mode: Instant playback, General playback, Event playback, Tag playback, Smart playback Interface Ports: 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) Backup Method: USB device and network Smart Phone: iOS, Android Ethernet: 1 (10/100/1000 Mbps Ethernet port, RJ-45) Browser: Chrome, IE, Safari, Edge, Firefox Power Supply: 12 VDC, 4 A Power Consumption: ≤ 10 W (without HDD) Operating Temperature: -10 °C to +55 °C (14 °F to +131 °F) Operating Humidity: 10%–93% (RH), non-condensing Storage Temperature: -20 °C to +60 °C (–4 °F to +140 °F) Dimensions: 375.0 mm × 282.9 mm × 53.0 mm Weight: 1490 g (without HDD)

Confirm the supplied items with our team.

Warranty information will be confirmed before purchase.
