SKU: MSI-367724 · Model: PRO A520M-S
In Stock
Enter your PIN code to find delivery options and a nearby store.
MSI PRO A520M-S Model: PRO A520M-S Chipset: AMD A520; CPU: Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processors; Socket AM4; Memory: 2x DDR4, Maximum Memory Capacity 64GB; Memory Support DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE; Ryzen™ 5000 Series Processors max. overclocking:; • 1DPC 1R Max speed up to 4600+ MT/s; • 1DPC 2R Max speed up to 3866+ MT/s; ; Supports JEDEC Speed; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Memory Overclocking by A-XMP OC mode; ; • The DIMM slots on this motherboard have double-sided latches.; Onboard Graphics: 1x HDMI™; Support HDMITM 1.4, maximum resolution of 4K 30Hz*; *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.; Slot: 1x PCI-E x16 slot (Qty); 1x PCI-E x1 slot (Qty); PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) ; PCI_E2 Gen PCIe 3.0 supports up to x16 (From CPU) ; *The supported specification depends on installed processor.; Audio: Realtek® ALC897 Codec; 7.1-Channel High Definition Audio; Storage: 1x M.2 (Qty); M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260 devices ; 4x SATA 6G (Qty); RAID: Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices; USB: 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 4x USB 5Gbps Type A (Rear); 2x USB 5Gbps Type A (Front); LAN: Realtek® RTL8111H 1Gbps LAN; Internal IO: 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 1x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 4x USB 2.0 ports; 2x USB 5Gbps Type A ports; LED FEATURE: 4x EZ Debug LED; OPERATING SYSTEM: Support for Windows® 11 64-bit; PCB Info: mATX; 200mmx236mm;
| CPU | Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processors; Socket AM4; |
|---|---|
| LAN | Realtek® RTL8111H 1Gbps LAN; |
| USB | 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 4x USB 5Gbps Type A (Rear); 2x USB 5Gbps Type A (Front); |
| RAID | Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices; |
| Slot | 1x PCI-E x16 slot (Qty); 1x PCI-E x1 slot (Qty); PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) ; PCI_E2 Gen PCIe 3.0 supports up to x16 (From CPU) ; *The supported specification depends on installed processor.; |
| Audio | Realtek® ALC897 Codec; 7.1-Channel High Definition Audio; |
| Model | PRO A520M-S |
| Memory | 2x DDR4, Maximum Memory Capacity 64GB; Memory Support DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE; Ryzen™ 5000 Series Processors max. overclocking:; • 1DPC 1R Max speed up to 4600+ MT/s; • 1DPC 2R Max speed up to 3866+ MT/s; ; Supports JEDEC Speed; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Memory Overclocking by A-XMP OC mode; ; • The DIMM slots on this motherboard have double-sided latches.; |
| Chipset | AMD A520; |
| Storage | 1x M.2 (Qty); M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260 devices ; 4x SATA 6G (Qty); |
| PCB Info | mATX; 200mmx236mm; |
| Internal IO | 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 1x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 4x USB 2.0 ports; 2x USB 5Gbps Type A ports; |
| LED FEATURE | 4x EZ Debug LED; |
| OPERATING SYSTEM | Support for Windows® 11 64-bit; |
| Onboard Graphics | 1x HDMI™; Support HDMITM 1.4, maximum resolution of 4K 30Hz*; *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.; |
